Dimensions
2072
Available surface finishes
2072
2072

2072

Product code: L.AVPW.2072
PARALLEL PREWIRED SURFACE MOUNTED LANDING OPERATOR PANELS
About

AVOX is ultra thin surface mounted landing operator panel series which is most popular and well-known in our product range. No visible bolts or screws due to smart snap fit design in the front panel. LED indicators and AVOX buttons are used in 9.9 mm slimcase which has tapered down to sides to even make a thinner look.

AVOX parallel prewired landing operator panels are developed for easier and faster installation for the parallel type elavator systems. The 9.9 mm slimcase of the AVOX has a modern thin look which doesn’t significantly stand out of the wall surface. But also has lack of space inside for wiring the components & organising the cables manually. Prewired models have all electronic parts on one board that all the required data and power inputs carry into a IDC socket. And it is connected to AV-TSV board in the shaft via IDC cable. Than connected to control panel with provided cables. Parallel prewired system offers time saving & cost effective professional looking shaft cabling and prevents from the connection mistakes.



Features

▪ Surface mounted, no screws for cover installation
▪ 9.9 mm ultra thin slim casing
▪ EN81-70 and EN81-28 compliant
▪ Decorative surface finishes available
▪ Parallel prewired type connection
