AVOX-CT4

9315.CT4D

Yükleniyor...

*illustrative purposes only. Images may have contain extra features

Dimensions
931.CT4D
Available surface finishes
available_finishes_light
AVOX-CT4

9315.CT4D

Product code: C.AVAC.9315.CT4D
SERIAL PREWIRED CAR OPERATOR PANELS
About

AVOX half & full height car operator panels with dual 4.3″ full color TFT floor position and information panels for elevator controllers which uses serial (CANBUS) communication. Simple plug and play connection structure needs no time to spend on electrical and mechanical installation. CKS keyboard modules are connected to CT4D. Lower TFT screen can be useful to show extra information respecting current floor position in graphics and text. Customer can change these images with using SDCARD and given PC software.

Features

▪ 480x272px RGB 24 bit TFT color indicator
▪ 4.3” indication area size
▪ Fiberglass, Polycarbonate lens cover
▪ RGB, programmable pictures for each floor
▪ Integrated Emergency light function (via second TFT)
▪ Built-in two ways intercom
▪ Integrated elevator ID function(via second TFT)
▪ 9.9mm surface mounted
▪ CANBUS, serial prewired type connection
▪ Plug type connection cable, (included)
▪ 2-30 stops (up to 99 stops via F keyboard)
▪ EN81-70, EN81-28 compliant
▪ Versatile, cost-effective, flexible design
