AVOX-MEGA7

7315.M7VT

Yükleniyor...

*illustrative purposes only. Images may have contain extra features

Dimensions
731.MEGA7V.TF
Available surface finishes
available_finishes_light
AVOX-MEGA7

7315.M7VT

Product code: C.AVAC.7315.M7VT
SERIAL PREWIRED CAR OPERATOR PANELS
About

AVOX Car Operator Panels with MEGA7 all in one integrated solution. CANBUS serial type connection is used with 7″ color TFT display.

Unique surface mounted design gives fexible and modern look.

New generation color TFT LCD type indicator panels have great advantage to show high resolution color images and real time high definition videos. Wide angle of visibility and crisp images with intense backlight brightness make MEGA7V.TF indicators are valuable for high-end elevators. Additional features like voice announcing, emergency state illumination, built-in communication systems results MEGA7V.TF is not only a simple floor position indicator but a complete in-car information panel for elevators. Elevator standards like EN81-20/28/70 are fully covered.

Features

â–ª Linux based cutting edge operation system
â–ª ARM Cortex A8 CPU with 4Gbit RAM
â–ª 800×480 pixel, 156x88mm (7″) TFT LCD
â–ª True color (16M) wide wieving angle
â–ª 125x180mm scratch resistant mineral cover glass
â–ª Voice announcing and high definition video playback
â–ª Floor level defined video and image showing
â–ª Seperate microphone and speaker for external autodialers
â–ª Built-in two ways intercom
â–ª USB and SDCARD interface
â–ª Ultra-bright emergency lamp (EN81-20)
â–ª Programmable input and output
â–ª Plug-jack type cable sets for easy installation
â–ª Configuration menu controlled via on-board buttons
â–ª Thin profile height to match AVOX series COPs
â–ª CANBUS serial type connection
â–ª EN81-70, EN81-28, EN81-20 compliant
â–ª Custom ID plate with laser marking
â–ª Decorative surface finishes available
