HERA

7215.GS7R

Yükleniyor...

*illustrative purposes only. Images may have contain extra features

Dimensions
HERA_COP_dimensions
Available surface finishes
available_finishes_light
HERA

7215.GS7R

GULL WING FLUSH MOUNTED CAR OPERATOR PANELS
Description

HERA is gull wing flush mounted car operator panel. 2 mm thick front panel is bended on sides to make even thinner look. Also supports the flat front panel. All the electronic components are well organised and safely hidden inside the backbox. Compatible with parallel type 7 Segment & LED matrix and LCD indicators. QUAD series premium quality push buttons and fixtures are used. User-friendly structure ensures reliable installation for wide range of elevator applications.

Features

â–ª Size 750x150mm, 985x194mm or custom height
â–ª Up to 12 stops
â–ª Brushed AISI 304L stainless steel framework
â–ª LCD, LED matrix or 7 Segment display options
â–ª Premium quality Quad buttons
â–ª Protrusion of ground landing buttons
â–ª Fan button with timer relay
â–ª Scratch resistant glass covered ID plate
